Latest company case about 3215-32.768KHz crystal resonator

3215-32.768KHz crystal resonator

7L Crystal Resonator. 3215-32.768KHz The 2-pad 3215 SMD size is one of the most widely used crystal packaging. Hermetically seam sealed in ceramic body and metal lid, it has good shock and environmental characteristics. With a great footprint, ESR, and pricing relationship, this Crystal is perfect for all sorts of portable, low-current applications. Features Compact and Low Profile 0.75 mm Height Seam Sealed High-Reliability Package Broadly Used Package 3215 SMD, 2-Pin T&R Packing for Automatic Mounting and Reflow Soldering Applications: RTC, Smart Meter, IoT, Automotive, Portable Devices RoHS Compliant & Pb-Free Specifications Type 7L SMD Crystal Frequency 32.768kHz Load Capacitance 6pF, 7pF, 9pF, 12.5pF Drive Level 1.0μW Max. Frequency Tolerance ±10ppm, ±20ppm Series Resistance 50kΩ, 70kΩ, or Specify Turnover Temperature ±25°C±5°C Parabolic Coefficient (0.03±0.01)*10-6/°C2 Operating Temperature -40 to +85°C, -55 to +125°C Storage Temperature -55 to +125°C Shunt Capacitance 1.0pF Typ. Aging (at 25°C) ±3ppm Max. at First Year Packing Unit 3000pcs/Reel Dimensions Units: mm Tolerance: ±0.1
