Half size osc

products
April 28, 2024
Category Connection: OCXO
Chat Now Contact Us
Tags:
#25 x 22 x 11mm ocxo oscillator #ocxo oscillator 10ppb #low phase noise ocxo 11mm
Brief: Discover the SMD 25 X 22 X 11mm Size OCXO, a high-performance Oven Controlled Crystal Oscillator supporting 5-40MHz at 3.3V. Ideal for base stations, test equipment, and more, this OCXO offers ±10ppb stability and fast warm-up.
Related Product Features:
  • OCXO (Oven Controlled Crystal Oscillator) with SC-Cut crystal unit for superior performance.
  • Compact SMD size of 25.4×22.1×11mm, suitable for automatic mounting and reflow soldering.
  • Wide frequency range from 5MHz to 40MHz, catering to diverse applications.
  • Exceptional frequency stability of ±10ppb over -40~+85℃ operating temperature.
  • Fast warm-up time, achieving ±0.1ppm stability in just 5 minutes.
  • Low phase noise, with -115dBc/Hz at 10Hz for precise signal generation.
  • RoHS Compliant & Pb-Free, ensuring environmental safety and compliance.
  • Versatile applications including base stations, digital switches, and test equipment.
Faqs:
  • What is the frequency range of the SMD OCXO?
    The SMD OCXO supports a frequency range from 5MHz to 40MHz.
  • What is the frequency stability of this OCXO?
    This OCXO offers a frequency stability of ±10ppb over an operating temperature range of -40~+85℃.
  • Is this OCXO suitable for automatic mounting?
    Yes, this OCXO is designed for automatic mounting and reflow soldering, making it ideal for high-volume production.
